Understand a Save Format With Hex Bytes and Controlled Changes

What you will learn

Decode an original four-byte record, identify endianness and validate a proposed schema.

1. Extract into a new folder and run node check.mjs from that folder.
2. For the browser games, run python3 -m http.server 8080 with Python 3 and open http://localhost:8080/index.html. Do not open modules with file://.
3. Read the full setup instructions and the original code licence. Keep your existing game on a separate test branch.

The JavaScript behaviour checks and native C comparison can run independently of the browser. Ghidra UI, physical-phone and your engine integration are separate checks. This is a small reference, not a certification of your project.

Explore the related game idea · Start with Build a Game · Improve your existing game

Five practical steps

1. Use an owned specimen

   This exercise studies an invented four-byte record from systems.mjs, not a commercial game save. The sample hex bytes are 01 0c 00 01. Save a copy and its hash before experimenting; work only on files you own or have permission to inspect.

   Expected result: A fixed specimen with known provenance.

   Check it: Confirm its size is four bytes; do not run an arbitrary downloaded binary.

   decodeRecordObserve the inputs → check the state → compare the result

2. Change one field at a time

   Create records for 12, 13 and 300 coins while keeping the room fixed. Compare bytes by offset. A change at one offset is evidence, but it does not prove there is no checksum, compression or wider field in another format.

   Expected result: An offset table derived from controlled inputs.

   Check it: Twelve to thirteen changes 0c to 0d; 300 is 2c 01 across two bytes.

3. Test the endian hypothesis

   For the middle two bytes, little-endian gives 0x012c = 300; big-endian gives 0x2c01 = 11265. Use DataView.getUint16(1,true) for the proposed little-endian field. Passing the actual byteOffset matters for slices of larger buffers.

   Expected result: A two-byte unsigned count consistent with all samples.

   Check it: Decode a four-byte subarray of a larger buffer and confirm it matches the direct sample.

4. Validate length and enums

   The reference checks exactly four bytes, version one and room zero or one. It returns a new data object and never interprets bytes as executable instructions. Unknown versions and lengths need explicit refusal, not a guess that destroys progress.

   Expected result: A small parser that rejects unsupported records.

   Check it: Try three bytes, version two and room three; each throws without modifying a game.

5. Document your confidence

   Write offset, width, signedness, endianness and observed range for each field. To study a different permitted save, repeat the controlled experiment and identify wrappers, checksums or compression from evidence. Do not transfer this toy layout to unrelated games.

   Expected result: A reproducible format note with limitations.

   Check it: Keep the original specimen, comparison samples and expected outputs so another person can repeat the conclusion.

Read and reuse the actual code

systems.mjs: complete source · Standalone behavioural checks · Shared browser runner and input. Original BINX Forge code, MIT; the package includes every required file and its notice.

// Original BINX Forge practice code. MIT; see LICENSE.txt.
export function readSave(raw) {
  const s = JSON.parse(raw);
  if (!s || s.version !== 1 || !Number.isInteger(s.coins) || s.coins < 0 || s.coins > 9999 || !['room-a','room-b'].includes(s.room)) throw Error('Invalid save');
  return {version:1, coins:s.coins, room:s.room};
}
export function transfer(from, to, id, count, capacity=10) {
  if (!Number.isInteger(count) || count < 1 || !Number.isInteger(from[id]) || from[id] < count || Object.values(to).reduce((a,b)=>a+b,0)+count > capacity) return false;
  from[id]-=count; to[id]=(to[id]||0)+count; return true;
}
export function pointerInput() {
  const owners=new Map();
  return {press:(id,action)=>owners.set(id,action),release:id=>owners.delete(id),clear:()=>owners.clear(),held:action=>[...owners.values()].includes(action)};
}
export function enemyMode(distance, hp, cooldown) {
  if (hp<=0) return 'dead';
  if (cooldown>0) return 'recover';
  if (distance<24) return 'attack';
  return distance<180?'chase':'idle';
}
export function frameSummary(samples) {
  const s=samples.filter(Number.isFinite).filter(x=>x>=0).sort((a,b)=>a-b);
  if (!s.length) throw Error('No samples');
  return {median:s[Math.floor((s.length-1)*.5)],p95:s[Math.ceil(s.length*.95)-1],count:s.length};
}
export function fixedStep(clock, elapsed, update) {
  clock.carry+=Math.max(0,Math.min(.1,elapsed));
  while(clock.carry>=1/60){update(1/60);clock.carry-=1/60;}
}
// Owned protocol specimen: version:u8, coins:u16 little-endian, room:u8.
export function decodeRecord(bytes) {
  if(bytes.length!==4)throw Error('Expected four bytes');
  const v=new DataView(bytes.buffer,bytes.byteOffset,bytes.byteLength);
  if(v.getUint8(0)!==1||v.getUint8(3)>1)throw Error('Unknown record');
  return {version:1,coins:v.getUint16(1,true),room:v.getUint8(3)};
}
export function applyInput(player, packet) {
  if(!packet||!Number.isInteger(packet.seq)||packet.seq<=player.seq||![-1,0,1].includes(packet.dx))return false;
  player.seq=packet.seq;player.x=Math.max(0,Math.min(100,player.x+packet.dx*2));return true;
}
export function jumpTrace(speed=300,gravity=900,dt=1/120) {
  let y=0,vy=-speed,t=0,peak=0;
  const rows=[{t,y,vy}];
  while(t<3){vy+=gravity*dt;y+=vy*dt;t+=dt;peak=Math.min(peak,y);rows.push({t,y,vy});if(y>=0)break;}
  return {rows,height:-peak,airtime:t};
}

Code rights: the included MIT notice permits use, modification and distribution, including commercial games and source products, with the copyright and licence notice. Added third-party files have their own terms. Read the official licence & usage terms.

Common failures and fixes

Make Your Game Better

Change one system after the baseline works. Keep the free reference and compare the same inputs before and after.

Licensing summary, not legal advice. Before publishing or selling, check exact terms for finished-game use, reselling files and including files in a source/template product separately.
